MATRIX CARD, 5/8"-1", LLS

The HydraSlitter® Matrix Card for 5/8" through 1" host pipe guides crews through selecting and assembling the correct tooling string for larger‑diameter lead service replacement. It maps out the proper tooling configuration based on both the host pipe and the new pipe size, illustrating the correct order of blades, cones, jaws, and separation tubes for each setup. The card also identifies the appropriate expander assembly for 5/8"–1" applications and shows exactly where it belongs within the tooling string, ensuring proper placement for optimal performance. With its clear, visual layout, the matrix card helps crews assemble the correct tooling string quickly and consistently, even in demanding field conditions.
